Yr 2009 LIEBHERR RL64 Litronic Sideboom Pipelayer
for rent
for sale
for rent
for sale
Manufacturer:
LIEBHERR
Model:
RL64 Litronic Sideboom Pipelayer
Lift capacity:
90,800 kgs
Length boom:
10,500 mm
Operating weight:
58,800 kgs
Emission standard:
EU Stage IIIA & US EPA Tier 3
Specifications
Specifications
We are offering a well-maintained yr 2009 LIEBHERR RL64 Litronic Sideboom Pipelayer with only 8,000 operating hours. With a lift capacity of 90,800 kg and powered by a proven 275 kW LIEBHERR engine, this machine delivers the strength, precision, and reliability essential for demanding pipeline construction projects.
- Year of manufacture 2009
- Recorded hours 8,000
- Operating weight 58,800 kgs
- LIft capacity 90,800 kgs
- Length boom 10,500 mm
- Type of boom Fixed boom
- Width track pads 914 mm
- Engine make & model LIEBHERR D946L A6
- Engine output 275 kW
- Emission standards EU Stage IIIA & US EPA Tier 3
- AdBlue DPF system No
- Fuel tank capacity 650 liters
- Certification CE
-
Configuration
• ROPS cab with heating
• Air conditioning
• Boom 10,500 mm
• Track pads 914 mm
• Centre track guide
• Acoustic back-up alarm
• Four (04) removable counterweights
• Hydraulic driven winch
• Hydraulic PTO to drive a mandrel or a pipefacing machine
• Free fall control
• Load monitoring system
• Arctic package -
Transport dimensions & weights
• Base machine: 5,800 mm x 4,250 mm x 3,650 mm
• Weight base machine: 42,580 kgs
• Boom: 10,850 mm x 1,450 mm x 700 mm
• Weight boom: 3,850 kgs
• 4 removable counterweights - each: 1,750 mm x 1,500 mm x 500 mm
• Weight each: 3,230 kgs - Country of manufacture Austria - EU
-
Remarks
• Machine is located in our yard in GOOR - The Netherlands
• Machine is available for sale and for rental
• Availability subject to prior sale or rental - Price On request:
Is a lift capacity of nearly 91 tonnes a too much for you?
If you do not need a lift capacity of 90,800 kgs then we can supply a 2008 LIEBHERR RL44 Litronic Sideboom Pipelayer.
Yr 2008 LIEBHERR RL44 Litronic Sideboom Pipelayer
Lift capacity:
nearly 47 tonnes
