Maats RL26
The Maats RL26 Sideboom Pipelayer offers a lifting capacity of 27.500 kg with an operating weight of approximately 23,300 kg. It is powered by the efficient Liebherr D942 A7 engine (107 kW), meeting EU Stage IV and USA EPA Tier 4 Final emission standards with AdBlue technology for reduced emissions.
Looking for more lifting capacity?
Explore the LIEBHERR RL44 Litronic
Need more information?
Please contact our sales department, they can and will be happy to help you.Specifications
Specifications
Built for versatility in pipeline applications, the RL26 combines compact dimensions with solid lifting performance. The hydrostatic travel drive allows precise maneuvering, even under load on uneven terrain. Equipped with a 7.000 mm boom, free fall control and a hydraulically driven winch, the machine ensures accurate control and consistent lifting dynamics. The standard ROPS cab with heating and air conditioning offers reliable operator comfort in various climates, while removable counterweights and a rear tow hitch provide flexibility on site.
- Certification CE
- Engine make & model Diesel Engine 90 kW
- Engine output 122 HP @ 2.100 rpm
- Emission standards EU Stage IV & USA EPA Tier4F
-
Standard configuration
Closed ROPS cabin with heater and airco
Center track guide
Back-up alarm (acoustic)
Counterweight including removable weight
5.160 mm boom, fixed
Hydraulic driven hoist winch
Free fall control
Hydraulic PTO
Lubricated single grouser track pads 762/762 mm -
Optional equipment
Load Monitoring System (LMS)
0-10 km/h infinitely variable travel speed (forward and reverse)
